Siemens 6AG1332-6SB00-7AY0 Power Supply

Key specifications

net weight: 0.2 kg
line frequency: 50/60 Hz
Product description: SIPLUS LOGO! POWER 24V 2.5 ASIPLUS LOGO! power 24 V 2.5 A based on 6EP3332-6SB00-0AY0 with conformal coating, -40…+70 °C, start up -25 °C, stabilized power supply input: 100-240 V AC output: 24 V DC/ 2.5 A
connection method — at input: L, N: 1 screw terminal each for 0.5 ... 2.5 mm2 single-core/finely stranded
mechanical data — width × height × depth of the enclosure: 54 × 90 × 53 mm

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Siemens 6AG1332-6SB00-7AY0 Power Supply
Brand	Siemens
Model	6AG1332-6SB00-7AY0
Category	Industrial Automation Parts
net weight	0.2 kg
line frequency	50/60 Hz
Product description	SIPLUS LOGO! POWER 24V 2.5 ASIPLUS LOGO! power 24 V 2.5 A based on 6EP3332-6SB00-0AY0 with conformal coating, -40…+70 °C, start up -25 °C, stabilized power supply input: 100-240 V AC output: 24 V DC/ 2.5 A
connection method — at input	L, N: 1 screw terminal each for 0.5 ... 2.5 mm2 single-core/finely stranded
mechanical data — width × height × depth of the enclosure	54 × 90 × 53 mm
installation altitude at height above sea level maximum	6 000 m
