Siemens 3NE3338-8 SITOR NH2 800 A aR Fuse Link
- Brand
- Siemens
- Model
- 3NE3338-8
- GEARWELL SKU
- GWP-000004384
- Category
- Industrial Automation Parts
Key specifications
- Fuse system size
- NH2
- Net Weight
- 793.5 g
- power loss [W]
- 130 W
- Rated current
- 800 A
- Rated voltage
- 800 V AC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Siemens 3NE3338-8 SITOR NH2 800 A aR Fuse Link |
|---|---|
| Brand | Siemens |
| Model | 3NE3338-8 |
| Category | Industrial Automation Parts |
| Fuse system size | NH2 |
| Net Weight | 793.5 g |
| power loss [W] | 130 W |
| Rated current | 800 A |
| Rated voltage | 800 V AC |
| Fuse operating class | aR |
| Contact and mounting arrangement | Slotted blade contacts; M10 screw fixing; 110 mm mounting dimension |
| Product description | SITOR fuse link, with slotted blade contacts, NH2, In: 800 A, aR, Un AC: 800 V, front indicator |
| Rated breaking capacity (AC) | 100 kA |
