SEW-EURODRIVE MDX61B00555A340T MOVIDRIVE B 5.5 kW Drive Inverter
- Brand
- SEW-EURODRIVE
- Model
- MDX61B00555A340T
- GEARWELL SKU
- GWP-000023223
- Category
- Variable Frequency Drives
Key specifications
- Size
- 2S
- Series
- MOVIDRIVE B MDX61B (options can be installed)
- Variant
- 0T = application version
- Quadrants
- 4Q (with brake chopper)
- Supply voltage
- 3 x AC 380-500 V, 50-60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SEW-EURODRIVE MDX61B00555A340T MOVIDRIVE B 5.5 kW Drive Inverter |
|---|---|
| Brand | SEW-EURODRIVE |
| Model | MDX61B00555A340T |
| Category | Variable Frequency Drives |
| Size | 2S |
| Series | MOVIDRIVE B MDX61B (options can be installed) |
| Variant | 0T = application version |
| Quadrants | 4Q (with brake chopper) |
| Supply voltage | 3 x AC 380-500 V, 50-60 Hz |
| Apparent output power | 8.7 kVA |
| Rated output current (400 V) | 12.5 A |
| Type designation (hyphenated) | MDX61B0055-5A3-4-0T |
| Radio interference suppression | A = class C2 on line side |
| Recommended motor power (constant load) | 5.5 kW |
