SEW-EURODRIVE MDX60A0110-5A3-4-00 MOVIDRIVE A 11 kW Drive Inverter
- Brand
- SEW-EURODRIVE
- Model
- MDX60A0110-5A3-4-00
- GEARWELL SKU
- GWP-000023222
- Category
- Variable Frequency Drives
Key specifications
- Series
- MOVIDRIVE A (MD_60A), size 2
- Weight
- 6.6 kg
- Supply voltage
- 3 x AC 380-500 V, 50-60 Hz
- Output rated power
- 16.8 kVA
- Dimensions W x H x D
- 130 x 336 x 325 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SEW-EURODRIVE MDX60A0110-5A3-4-00 MOVIDRIVE A 11 kW Drive Inverter |
|---|---|
| Brand | SEW-EURODRIVE |
| Model | MDX60A0110-5A3-4-00 |
| Category | Variable Frequency Drives |
| Series | MOVIDRIVE A (MD_60A), size 2 |
| Weight | 6.6 kg |
| Supply voltage | 3 x AC 380-500 V, 50-60 Hz |
| Output rated power | 16.8 kVA |
| Dimensions W x H x D | 130 x 336 x 325 mm |
| Min. braking resistor (4Q) | 22 ohm |
| Code position "X" in MDX60A | as collected; the MD_60A system manual lists F/V/S (MDF60A/MDV60A/MDS60A) for this size |
| Rated output current (400 V) | 24 A |
| Rated system current (400 V, 100 %) | 21.6 A |
| Recommended motor power (constant load) | 11 kW |
