Setra CSSGA2100NN Model CSS Solid-Core Current Switch
- Brand
- Setra
- Model
- CSSGA2100NN
- GEARWELL SKU
- GWP-000022173
- Category
- Test & Measurement
Key specifications
- Dimensions
- 2.54 x 1.85 x 0.98 in. (65 x 47 x 25 mm)
- Description
- Model CSS, Adjustable Setpoint, with LED, 1.00 A Setpoint, No Snap-on Power Relay
- Aperture size
- 0.71 in. (18 mm) dia.
- Status output
- Switch normally open, 1 A @ 30 VAC/DC max.
- Amperage range
- 1.00 to 135 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra CSSGA2100NN Model CSS Solid-Core Current Switch |
|---|---|
| Brand | Setra |
| Model | CSSGA2100NN |
| Category | Test & Measurement |
| Dimensions | 2.54 x 1.85 x 0.98 in. (65 x 47 x 25 mm) |
| Description | Model CSS, Adjustable Setpoint, with LED, 1.00 A Setpoint, No Snap-on Power Relay |
| Aperture size | 0.71 in. (18 mm) dia. |
| Status output | Switch normally open, 1 A @ 30 VAC/DC max. |
| Amperage range | 1.00 to 135 A |
| Agency approvals | CE, RoHS, c-UL Listed 508 (E317719) |
| Temperature range | -15 to 60 °C |
| Current switching mode | Over/Under Current Sensing |
| Continuous operating current | 125 A, 600 VAC |
