Setra 2701100PG1F2B02NCN Model 270 Pressure Transducer
- Brand
- Setra
- Model
- 2701100PG1F2B02NCN
- GEARWELL SKU
- GWP-000016488
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 2B = 0 to 5 VDC (24 VDC excitation)
- Options
- CN = 11 PT calibration certificate
- Accuracy
- N = ±0.05 % FS
- Model code
- 2701 = Model 270
- Termination
- 02 = 2 ft cable
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Setra 2701100PG1F2B02NCN Model 270 Pressure Transducer |
|---|---|
| Brand | Setra |
| Model | 2701100PG1F2B02NCN |
| Category | Pressure, Flow & Temperature |
| Output | 2B = 0 to 5 VDC (24 VDC excitation) |
| Options | CN = 11 PT calibration certificate |
| Accuracy | N = ±0.05 % FS |
| Model code | 2701 = Model 270 |
| Termination | 02 = 2 ft cable |
| Pressure range | 100 = 0 to 100 PSI |
| Pressure fitting | 1F = 1/8" NPT internal |
| Units / pressure type | P = PSI, G = Gauge |
