Schneider Electric ZC2JC1 Telemecanique Limit switches XC Standard Limit switch body

Key specifications

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Schneider Electric ZC2JC1 Telemecanique Limit switches XC Standard Limit switch body
Brand	Schneider Electric
Model	ZC2JC1
Category	Proximity & Photoelectric Sensors
Body type	Fixed
Cable entry	1 tapped entry for Pg 13.5 cable gland (included)
Series name	Standard format
Body material	Metal
Local display	Without
Number of poles	1
Number of steps	1 1 position
Positive opening	Without
Contact operation	Snap action
Contacts material	Silver plated contacts
Device short name	ZC2J
Electrical connection	Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
Electrical durability	5000000 Cycles, DC-13 120 V, 4 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC / 5000000 Cycles, DC-13 24 V, 10 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC / 5000000 Cycles, DC-13 48 V, 7 W, operating rate <60 cyc/mn, load factor: 0.5 conforming to IEC
Minimum actuation speed	0.01 M/Min
Short-circuit protection	10 A cartridge fuse, type gG
[Ui] rated insulation voltage	500 V conforming to IEC 60947-1 for contact block / 300 V conforming to CSA C22.2 No 14 for contact block
[Ie] rated operational current	3 A at 240 V, AC-15, A300 conforming to IEC 60947-5-1 appendix A / 0.27 A at 250 V, DC-13, Q300 conforming to IEC 60947-5-1 appendix A
Contacts type and composition	1 C/O
Maximum resistance across terminals	0.25 MOhm conforming to IEC 60255-7 category 3
[Ithe] conventional enclosed thermal current	10 A
