Schneider Electric VW3A3407 Altivar Encoder Interface Card
- Brand
- Schneider Electric
- Model
- VW3A3407
- GEARWELL SKU
- GWP-000011098
- Category
- Variable Frequency Drives
Key specifications
- Input signal
- A, B, Compliment of A, Compliment of B/AB/A
- Protection type
- Overload protection, Short-circuit protection
- Discrete output type
- Push-pull
- Maximum supply current
- 0.175 A
- [Us] rated supply voltage
- 24 V DC (voltage limits: 20…30 V)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric VW3A3407 Altivar Encoder Interface Card |
|---|---|
| Brand | Schneider Electric |
| Model | VW3A3407 |
| Category | Variable Frequency Drives |
| Input signal | A, B, Compliment of A, Compliment of B/AB/A |
| Protection type | Overload protection, Short-circuit protection |
| Discrete output type | Push-pull |
| Maximum supply current | 0.175 A |
| [Us] rated supply voltage | 24 V DC (voltage limits: 20…30 V) |
| Maximum operating frequency | 300 kHz |
| Number of pulses per revolution | 10000 for ATV71H......383, 5000 for all ATV61 drives, 5000 for ATV71H...M3, 5000 for ATV71H...M3X, 5000 for ATV71H...N4 |
| Maximum cable distance between devices | 500 M |
