Schneider Electric TSX3721101 Modicon TSX Micro automation platform Modular base controller
- Brand
- Schneider Electric
- Model
- TSX3721101
- GEARWELL SKU
- GWP-000017312
- Category
- PLCs & I/O
Key specifications
- Input current
- 2 MA 60 A
- Realtime clock
- With
- Number of slots
- 3
- Primary voltage
- 24 V 19.2…30 V DC
- Protection type
- Short-circuit / Overload protection
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric TSX3721101 Modicon TSX Micro automation platform Modular base controller |
|---|---|
| Brand | Schneider Electric |
| Model | TSX3721101 |
| Category | PLCs & I/O |
| Input current | 2 MA 60 A |
| Realtime clock | With |
| Number of slots | 3 |
| Primary voltage | 24 V 19.2…30 V DC |
| Protection type | Short-circuit / Overload protection |
| System overhead | 1.6 Ms for master task |
| Memory description | Flash 15 Kwords data / Internal RAM 20 Kwords data / Internal RAM (with PCMCIA card) 128 Kwords program and data / Internal RAM 128 Kwords data storage |
| Application structure | 1 fast task / 16 event tasks / 1 master task |
| Immunity to microbreaks | 10 Ms |
| Integrated connection type | 1 serial link (TER/AUX) Uni-Telway 19.2 kbit/s / 1 Modbus Modbus RTU 19.2 kbit/s |
| Total useful secondary power | 16 W |
| Execution time per instruction | 0.13 µs Boolean without PCMCIA card / 4.5 µs arithmetic REAL floating without PCMCIA card / 0.19 µs Boolean with PCMCIA card / 4.5 µs arithmetic REAL floating with PCMCIA card |
