Schneider Electric TCSESPU093F2CU0 Modicon Networking Ethernet TCP/IP unmanaged switch
- Brand
- Schneider Electric
- Model
- TCSESPU093F2CU0
- GEARWELL SKU
- GWP-000032017
- Category
- Industrial Communication
Key specifications
- Net weight
- 0.510 kg
- Ethernet ports
- 10/100BASE-TX - 7 copper; 100BASE-FX - 2 fiber optic
- Power consumption
- 6.9 W
- Optic fiber length
- 4 km 62.5/125 µm; 5 km 50/125 µm
- Rated supply voltage
- 12...24 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric TCSESPU093F2CU0 Modicon Networking Ethernet TCP/IP unmanaged switch |
|---|---|
| Brand | Schneider Electric |
| Model | TCSESPU093F2CU0 |
| Category | Industrial Communication |
| Net weight | 0.510 kg |
| Ethernet ports | 10/100BASE-TX - 7 copper; 100BASE-FX - 2 fiber optic |
| Power consumption | 6.9 W |
| Optic fiber length | 4 km 62.5/125 µm; 5 km 50/125 µm |
| Rated supply voltage | 12...24 V |
| Supply voltage limits | 9.6…32 V DC SELV |
