Schneider Electric NSYCVF165M230PF Enclosure Ventilation Fan
- Brand
- Schneider Electric
- Model
- NSYCVF165M230PF
- GEARWELL SKU
- GWP-000007379
- Category
- Compressors & Fans
Key specifications
- Air flow
- Free flow rate with standard filter: 165 m3/h at 50 Hz, Free flow rate with standard filter: 193 m3/h at 60 Hz
- Noise level
- 50…51 DB
- Power range
- 16.3 W 50 Hz, 14.3 W 60 Hz
- Input voltage
- 230 V 50/60 Hz
- [In] rated current
- 0.12 A 50 Hz, 0.94 A 60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric NSYCVF165M230PF Enclosure Ventilation Fan |
|---|---|
| Brand | Schneider Electric |
| Model | NSYCVF165M230PF |
| Category | Compressors & Fans |
| Air flow | Free flow rate with standard filter: 165 m3/h at 50 Hz, Free flow rate with standard filter: 193 m3/h at 60 Hz |
| Noise level | 50…51 DB |
| Power range | 16.3 W 50 Hz, 14.3 W 60 Hz |
| Input voltage | 230 V 50/60 Hz |
| [In] rated current | 0.12 A 50 Hz, 0.94 A 60 Hz |
| Product certifications | CSA |
| [Us] rated supply voltage | 175...253 V |
| Type of ventilation filter | Standard |
