Schneider Electric LXM32SD30M2 Lexium 32 Motion servo drive

Key specifications

Nominal power: 0.8 KW at 115 V 8 kHz ; 1.6 KW at 230 V 8 kHz
Range of product: Lexium 32
Output current 3s peak: 15 A at 115 V for 5 s ; 30 A at 230 V for 5 s
Communication interface: SERCOS III, integrated
[Us] rated supply voltage: 100...120 V - 15...10 % ; 200...240 V - 15...10 %

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Schneider Electric LXM32SD30M2 Lexium 32 Motion servo drive
Brand	Schneider Electric
Model	LXM32SD30M2
Category	Servo Systems
Nominal power	0.8 KW at 115 V 8 kHz ; 1.6 KW at 230 V 8 kHz
Range of product	Lexium 32
Output current 3s peak	15 A at 115 V for 5 s ; 30 A at 230 V for 5 s
Communication interface	SERCOS III, integrated
[Us] rated supply voltage	100...120 V - 15...10 % ; 200...240 V - 15...10 %
Network number of phases	Single phase
Continuous output current	10 A at 8 kHz
