Schneider Electric BSH1004P11F2A Lexium 32, Lexium 15, Lexium 05 Servo motor
- Brand
- Schneider Electric
- Model
- BSH1004P11F2A
- GEARWELL SKU
- GWP-000031924
- Category
- Servo Systems
Key specifications
- Shaft end
- Keyed
- Feedback type
- Single turn SinCos Hiperface
- Holding brake
- With
- Nominal speed
- 2500 rpm for LXM32.D30N4 at 10 A, 400 V, three phase
- Peak stall torque
- 37.9 N.M for LXM32.D30N4 at 10 A, 400 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH1004P11F2A Lexium 32, Lexium 15, Lexium 05 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH1004P11F2A |
| Category | Servo Systems |
| Shaft end | Keyed |
| Feedback type | Single turn SinCos Hiperface |
| Holding brake | With |
| Nominal speed | 2500 rpm for LXM32.D30N4 at 10 A, 400 V, three phase |
| Peak stall torque | 37.9 N.M for LXM32.D30N4 at 10 A, 400 V, three phase |
| Continuous stall torque | 8 N.M for LXM32.D30N4 at 10 A, 400 V, three phase |
| Maximum mechanical speed | 6000 Rpm |
| Product or component type | Servo motor |
