Schneider Electric BSH1001T11F2A Lexium 05, Lexium 32, Lexium 15 Servo motor
- Brand
- Schneider Electric
- Model
- BSH1001T11F2A
- GEARWELL SKU
- GWP-000031921
- Category
- Servo Systems
Key specifications
- Feedback type
- Single turn SinCos Hiperface
- Holding brake
- With
- Nominal speed
- 2500 rpm for LXM32.D30M2 at 10 A, 115 V, single phase
- Peak stall torque
- 6.3 N.M for LXM32.D30M2 at 10 A, 115 V, single phase
- Nominal output power
- 700 W for LXM32.D30M2 at 10 A, 115 V, single phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH1001T11F2A Lexium 05, Lexium 32, Lexium 15 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH1001T11F2A |
| Category | Servo Systems |
| Feedback type | Single turn SinCos Hiperface |
| Holding brake | With |
| Nominal speed | 2500 rpm for LXM32.D30M2 at 10 A, 115 V, single phase |
| Peak stall torque | 6.3 N.M for LXM32.D30M2 at 10 A, 115 V, single phase |
| Nominal output power | 700 W for LXM32.D30M2 at 10 A, 115 V, single phase |
| Continuous stall torque | 3.3 N.M for LXM32.D30M2 at 10 A, 115 V, single phase |
| Maximum mechanical speed | 6000 Rpm |
| Product or component type | Servo motor |
