Schneider Electric BSH0701P12A1A Lexium 15, Lexium 05, Lexium 32 Servo motor
- Brand
- Schneider Electric
- Model
- BSH0701P12A1A
- GEARWELL SKU
- GWP-000031916
- Category
- Servo Systems
Key specifications
- Shaft end
- Keyed
- Feedback type
- Multiturn SinCos Hiperface
- Holding brake
- Without
- Peak stall torque
- 3.5 N.M for LXM32.D12N4 at 3 A, 400 V, three phase
- Nominal output power
- 700 W for LXM32.D12N4 at 3 A, 400 V, three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH0701P12A1A Lexium 15, Lexium 05, Lexium 32 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH0701P12A1A |
| Category | Servo Systems |
| Shaft end | Keyed |
| Feedback type | Multiturn SinCos Hiperface |
| Holding brake | Without |
| Peak stall torque | 3.5 N.M for LXM32.D12N4 at 3 A, 400 V, three phase |
| Nominal output power | 700 W for LXM32.D12N4 at 3 A, 400 V, three phase |
| Continuous stall torque | 1.4 N.M for LXM32.D12N4 at 3 A, 400 V, three phase |
| Maximum mechanical speed | 8000 Rpm |
| Product or component type | Servo motor |
