Schneider Electric BSH0552T01F2A Lexium 05, Lexium 32, Lexium 15 Servo motor
- Brand
- Schneider Electric
- Model
- BSH0552T01F2A
- GEARWELL SKU
- GWP-000031876
- Category
- Servo Systems
Key specifications
- Shaft end
- Untapped
- Feedback type
- Single turn SinCos Hiperface
- Holding brake
- With
- Peak stall torque
- 1.9 N.M for LXM32.U90M2 at 3 A, 115 V, single phase
- Nominal output power
- 250 W for LXM32.U90M2 at 3 A, 115 V, single phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BSH0552T01F2A Lexium 05, Lexium 32, Lexium 15 Servo motor |
|---|---|
| Brand | Schneider Electric |
| Model | BSH0552T01F2A |
| Category | Servo Systems |
| Shaft end | Untapped |
| Feedback type | Single turn SinCos Hiperface |
| Holding brake | With |
| Peak stall torque | 1.9 N.M for LXM32.U90M2 at 3 A, 115 V, single phase |
| Nominal output power | 250 W for LXM32.U90M2 at 3 A, 115 V, single phase |
| Continuous stall torque | 0.8 N.M for LXM32.U90M2 at 3 A, 115 V, single phase |
| Maximum mechanical speed | 9000 Rpm |
| Product or component type | Servo motor |
