Schneider Electric BMXAMI0810 Modicon X80 Analog input module

Key specifications

Input impedance: 10 MΩ in voltage mode
Analogue input type: +/-20 mA, 0...20 mA, 4...20 mA, +/-10 V, +/-5 V, 0...10 V, 0...5 V, 1...5 V
Analogue input number: 8
Electrical connection: 28 ways 1 connector
Input output isolation: Isolated

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	Schneider Electric BMXAMI0810 Modicon X80 Analog input module
Brand	Schneider Electric
Model	BMXAMI0810
Category	PLCs & I/O
Input impedance	10 MΩ in voltage mode
Analogue input type	+/-20 mA, 0...20 mA, 4...20 mA, +/-10 V, +/-5 V, 0...10 V, 0...5 V, 1...5 V
Analogue input number	8
Electrical connection	28 ways 1 connector
Input output isolation	Isolated
Analog/digital conversion	16 bits
Analogue input resolution	15 bits + sign
