Schneider Electric BMI1003P01F Lexium 32i Servo motor with power stage
- Brand
- Schneider Electric
- Model
- BMI1003P01F
- GEARWELL SKU
- GWP-000031866
- Category
- Servo Systems
Key specifications
- Shaft end
- Untapped
- Feedback type
- Absolute single turn SinCos Hiperface
- Nominal speed
- 1500 rpm at 208 V three phase
- Peak stall torque
- 19.2 N.M at 400 V three phase
- Nominal output power
- 1000 W at 208 V three phase
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric BMI1003P01F Lexium 32i Servo motor with power stage |
|---|---|
| Brand | Schneider Electric |
| Model | BMI1003P01F |
| Category | Servo Systems |
| Shaft end | Untapped |
| Feedback type | Absolute single turn SinCos Hiperface |
| Nominal speed | 1500 rpm at 208 V three phase |
| Peak stall torque | 19.2 N.M at 400 V three phase |
| Nominal output power | 1000 W at 208 V three phase |
| Continuous stall torque | 8.5 N.M at 208...480 V three phase |
| Maximum mechanical speed | 6000 Rpm |
| Product or component type | Servo motor with power stage |
