Schneider Electric AS-BADU-204 Modicon A120 Series I/O (Compact 984) Analog input module
- Brand
- Schneider Electric
- Model
- AS-BADU-204
- GEARWELL SKU
- GWP-000031781
- Category
- PLCs & I/O
Key specifications
- Power supply
- 5 V, < 50 mA from I/O bus
- RTD resolution
- 0.25 °C
- Input impedance
- > 10 MΩ
- Number of channels
- 4
- Signal types supported
- Two-pole voltage inputs; four-pole RTD inputs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric AS-BADU-204 Modicon A120 Series I/O (Compact 984) Analog input module |
|---|---|
| Brand | Schneider Electric |
| Model | AS-BADU-204 |
| Category | PLCs & I/O |
| Power supply | 5 V, < 50 mA from I/O bus |
| RTD resolution | 0.25 °C |
| Input impedance | > 10 MΩ |
| Number of channels | 4 |
| Signal types supported | Two-pole voltage inputs; four-pole RTD inputs |
| Voltage linear measuring range | +/- 0.5 V nominal |
| RTD temperature measuring range | -200...+850 °C |
