Schneider Electric 60144 Multi9 C60 UL489 Miniature circuit breaker
- Brand
- Schneider Electric
- Model
- 60144
- GEARWELL SKU
- GWP-000032213
- Category
- Circuit Protection
Key specifications
- Standards
- GB 14048.2; EN/IEC 60947-2; UL 489
- Curve code
- C
- Network type
- AC; DC
- [In] rated current
- 10 A at 25 °C
- Neutral position
- Left
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric 60144 Multi9 C60 UL489 Miniature circuit breaker |
|---|---|
| Brand | Schneider Electric |
| Model | 60144 |
| Category | Circuit Protection |
| Standards | GB 14048.2; EN/IEC 60947-2; UL 489 |
| Curve code | C |
| Network type | AC; DC |
| [In] rated current | 10 A at 25 °C |
| Neutral position | Left |
| Breaking capacity | 6 KA Icu at 440 V AC conforming to EN/IEC 60947-2; 10 KA Icu at 415 V AC conforming to EN/IEC 60947-2; 20 KA Icu at 240 V AC conforming to EN/IEC 60947-2 |
| Poles description | 2P |
| Device application | Distribution |
| Trip unit technology | Thermal-magnetic |
| Number of protected poles | 2 |
| Product or component type | Miniature circuit-breaker |
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
