Schneider Electric 170INT11003 Modicon Momentum automation platform Interbus communication adaptor
- Brand
- Schneider Electric
- Model
- 170INT11003
- GEARWELL SKU
- GWP-000017301
- Category
- Industrial Communication
Key specifications
- Depth
- 259 Mm
- Width
- 178 Mm
- Height
- 56 Mm
- Topology
- Ring
- Fail state
- Fail safe
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric 170INT11003 Modicon Momentum automation platform Interbus communication adaptor |
|---|---|
| Brand | Schneider Electric |
| Model | 170INT11003 |
| Category | Industrial Communication |
| Depth | 259 Mm |
| Width | 178 Mm |
| Height | 56 Mm |
| Topology | Ring |
| Fail state | Fail safe |
| Net weight | 0.07 Kg |
| Cable length | 12800 M / 400 M |
| Method of access | Master/Slave / Continuous shift register |
| Control parameter | CRC-16 |
| Transmission rate | 500 kbit/s |
| Communication port protocol | Interbus generation SUPI 3 |
| Transmission support medium | Twisted pair |
