Schneider Electric 140CPS21400 Modicon Quantum automation platform Power supply module
- Brand
- Schneider Electric
- Model
- 140CPS21400
- GEARWELL SKU
- GWP-000017295
- Category
- Power Supplies
Key specifications
- Net weight
- 0.65 Kg
- Alarm output
- 1 NC 6 A 220 V power supply fault
- Input current
- 3800 MA
- Input voltage
- 24 V (20...30 V) DC
- Inrush current
- 14 A 20 V / 25 A 24 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Schneider Electric 140CPS21400 Modicon Quantum automation platform Power supply module |
|---|---|
| Brand | Schneider Electric |
| Model | 140CPS21400 |
| Category | Power Supplies |
| Net weight | 0.65 Kg |
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Input current | 3800 MA |
| Input voltage | 24 V (20...30 V) DC |
| Inrush current | 14 A 20 V / 25 A 24 V |
| Output voltage | 5.1 V DC |
| Power dissipation | 6 + (1.8 x Iout) where Iout is in A |
| Power supply type | Summable |
| Associated fuse rating | 5 A, slow-blow |
| Output overload protection | Internal |
| Power supply output current | 8 A summable |
| Output overvoltage protection | Internal |
| Maximum input power interruption | 100 Ms / 1 Ms 20 V |
