Sanyo Denki R2AA06020FCP11M SANMOTION R AC Servo Motor 200 W
- Brand
- Sanyo Denki
- Model
- R2AA06020FCP11M
- GEARWELL SKU
- GWP-000023473
- Category
- Servo Systems
Key specifications
- Max. speed
- 6000 min-1
- Rated speed
- 3000 min-1
- Rated output
- 0.2 kW
- Rated torque
- 0.637 N·m
- Code suffix "CP11M"
- as collected; not listed in the official SANMOTION R lineup (base type R2AA06020F confirmed)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Sanyo Denki R2AA06020FCP11M SANMOTION R AC Servo Motor 200 W |
|---|---|
| Brand | Sanyo Denki |
| Model | R2AA06020FCP11M |
| Category | Servo Systems |
| Max. speed | 6000 min-1 |
| Rated speed | 3000 min-1 |
| Rated output | 0.2 kW |
| Rated torque | 0.637 N·m |
| Code suffix "CP11M" | as collected; not listed in the official SANMOTION R lineup (base type R2AA06020F confirmed) |
| Motor flange size | 60 mm |
| Peak stall torque | 2.2 N·m |
| Motor classification | Rotary (medium inertia) |
| Continuous stall torque | 0.686 N·m |
