ProSoft Technology 5302-MBP-MCM4 ProLinx Modbus Plus Gateway
- Brand
- ProSoft Technology
- Model
- 5302-MBP-MCM4
- GEARWELL SKU
- GWP-000025565
- Category
- Industrial Communication
Key specifications
- Mounting
- DIN rail, extruded aluminum housing
- Baud rate
- 110 to 115K baud
- Brand note
- collected as WOODWARD; manufacturer is ProSoft Technology
- Current load
- 500 mA max @ 24 VDC
- Power supply
- 24 VDC nominal, 18 to 36 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ProSoft Technology 5302-MBP-MCM4 ProLinx Modbus Plus Gateway |
|---|---|
| Brand | ProSoft Technology |
| Model | 5302-MBP-MCM4 |
| Category | Industrial Communication |
| Mounting | DIN rail, extruded aluminum housing |
| Baud rate | 110 to 115K baud |
| Brand note | collected as WOODWARD; manufacturer is ProSoft Technology |
| Current load | 500 mA max @ 24 VDC |
| Power supply | 24 VDC nominal, 18 to 36 VDC |
| Modbus Plus ports | 1 (DB9 female, master/slave) |
| Modbus serial ports | up to 4 (master/slave, RTU or ASCII) |
| Modbus Plus address scope | 1 to 64 |
