Pioneer Magnetics PM3398B-6P-1-3P-E PowerFactor AC-DC Power Supply
- Brand
- Pioneer Magnetics
- Model
- PM3398B-6P-1-3P-E
- GEARWELL SKU
- GWP-000034796
- Category
- Power Supplies
Key specifications
- Series
- PM33 - PowerFactor (AC to DC)
- Evidence
- Pioneer Magnetics catalogue (PMI_Catalog3.pdf), Section 10 pages 22-23 and Section 27 model number description
- I/O interface
- no P designator after case letter = non-plug
- AC input (code 6P)
- three-phase, 90 to 264 VAC
- Code suffix "-1-3P-E"
- as collected; not decoded with certainty from the official model-number table (later positions include PMI internal input/output module information)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Pioneer Magnetics PM3398B-6P-1-3P-E PowerFactor AC-DC Power Supply |
|---|---|
| Brand | Pioneer Magnetics |
| Model | PM3398B-6P-1-3P-E |
| Category | Power Supplies |
| Series | PM33 - PowerFactor (AC to DC) |
| Evidence | Pioneer Magnetics catalogue (PMI_Catalog3.pdf), Section 10 pages 22-23 and Section 27 model number description |
| I/O interface | no P designator after case letter = non-plug |
| AC input (code 6P) | three-phase, 90 to 264 VAC |
| Code suffix "-1-3P-E" | as collected; not decoded with certainty from the official model-number table (later positions include PMI internal input/output module information) |
| Max output power (code digit 8) | 1500 W |
| Case cross section (code letter B) | 5 in x (4.75 in to 5.25 in) |
| PM3398 family features (catalogue) | power factor corrected, 20 ms hold-up, internal forced-air cooling, overload protection, 0 to +50 °C at full load |
