People Electric RDCPS-45C/M13/09MG Control and Protective Switch

Key specifications

Controller: M (economy type intelligent controller)
Derived code: G (isolation)
Material number: 101002012010996
Rated current "13 A": as collected; not in the official rated-current list (0.25 ... 125 A)
Frame (shell) current: 45 A

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	People Electric RDCPS-45C/M13/09MG Control and Protective Switch
Brand	People Electric
Model	RDCPS-45C/M13/09MG
Category	Contactors & Starters
Controller	M (economy type intelligent controller)
Derived code	G (isolation)
Material number	101002012010996
Rated current "13 A"	as collected; not in the official rated-current list (0.25 ... 125 A)
Frame (shell) current	45 A
Auxiliary contact code	09 (5 NO + 4 NC + 1 short-circuit + 1 fault signal contact)
Control supply voltage	AC 220 (code M) V
Rated insulation voltage Ui	690 V
Intelligent controller rated current Ie	13 (as collected) A
Rated service short-circuit breaking capacity Ics (code C)	12 kA
