People Electric RDCPS-45C/M0.63/06M Control and Protective Switch
- Brand
- People Electric
- Model
- RDCPS-45C/M0.63/06M
- GEARWELL SKU
- GWP-000020715
- Category
- Contactors & Starters
Key specifications
- Controller
- M (economy type intelligent controller)
- Material number
- 101002012011026
- Frame (shell) current
- 45 A
- Rated current "0.63 A"
- as collected; not in the official rated-current list (0.25 ... 125 A)
- Auxiliary contact code
- 06 (3 NO + 3 NC + 1 short-circuit + 1 fault signal contact)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | People Electric RDCPS-45C/M0.63/06M Control and Protective Switch |
|---|---|
| Brand | People Electric |
| Model | RDCPS-45C/M0.63/06M |
| Category | Contactors & Starters |
| Controller | M (economy type intelligent controller) |
| Material number | 101002012011026 |
| Frame (shell) current | 45 A |
| Rated current "0.63 A" | as collected; not in the official rated-current list (0.25 ... 125 A) |
| Auxiliary contact code | 06 (3 NO + 3 NC + 1 short-circuit + 1 fault signal contact) |
| Control supply voltage | AC 220 (code M) V |
| Rated insulation voltage Ui | 690 V |
| Intelligent controller rated current Ie | 0.63 (as collected) A |
| Rated service short-circuit breaking capacity Ics (code C) | 12 kA |
