PANASONIC MQMF012L1V2M MINAS A6 MQMF 100W AC Servo Motor
- Brand
- PANASONIC
- Model
- MQMF012L1V2M
- GEARWELL SKU
- GWP-000021522
- Category
- Servo Systems
Key specifications
- Family
- MINAS A6
- Series
- MQMF Series
- Flange size
- 60 mm sq.
- Rated output
- 100 W
- Rated torque
- 0.32 N·m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC MQMF012L1V2M MINAS A6 MQMF 100W AC Servo Motor |
|---|---|
| Brand | PANASONIC |
| Model | MQMF012L1V2M |
| Category | Servo Systems |
| Family | MINAS A6 |
| Series | MQMF Series |
| Flange size | 60 mm sq. |
| Rated output | 100 W |
| Rated torque | 0.32 N·m |
| Holding brake | with |
| Rotary encoder | 23-bit absolute/incremental |
| Rated / max. speed | 3000 / 6500 r/min |
| Protection class | IP65 |
| Momentary max. peak torque | 1.11 N·m |
