OMRON K3HB-SSD-CPAC21 AC/DC24 K3HB-S Linear sensor indicator (digital panel meter)
- Brand
- OMRON
- Model
- K3HB-SSD-CPAC21 AC/DC24
- GEARWELL SKU
- GWP-000031412
- Category
- Test & Measurement
Key specifications
- Input
- DC process (0–20 mA, 4–20 mA, 0–5 V, 1–5 V, ±5 V, ±10 V)
- Display
- Negative LCD, PV character height 14.2 mm
- Outputs
- Relay PASS (SPDT) + relay HH/H/LL/L (SPST-NO each)
- Event inputs
- 5 inputs, M3 terminal block, NPN
- Sampling period
- 0.5 ms (one input)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON K3HB-SSD-CPAC21 AC/DC24 K3HB-S Linear sensor indicator (digital panel meter) |
|---|---|
| Brand | OMRON |
| Model | K3HB-SSD-CPAC21 AC/DC24 |
| Category | Test & Measurement |
| Input | DC process (0–20 mA, 4–20 mA, 0–5 V, 1–5 V, ±5 V, ±10 V) |
| Display | Negative LCD, PV character height 14.2 mm |
| Outputs | Relay PASS (SPDT) + relay HH/H/LL/L (SPST-NO each) |
| Event inputs | 5 inputs, M3 terminal block, NPN |
| Sampling period | 0.5 ms (one input) |
| Sensor power supply | 12 VDC ±10%, 80 mA |
| Power supply voltage | 24 VAC/VDC |
