OMRON K2CU-F10A-E K2CU Heater Element Burnout Detector
- Brand
- OMRON
- Model
- K2CU-F10A-E
- GEARWELL SKU
- GWP-000015626
- Category
- Pressure, Flow & Temperature
Key specifications
- Type
- Large-capacity, built-in current transformer
- Operate time
- 0.5 s max.
- Control output
- 2 A at 220 VAC, SPDT
- Ambient temperature
- -10 to 55 °C
- Control supply voltage
- 200 VAC, 50/60 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON K2CU-F10A-E K2CU Heater Element Burnout Detector |
|---|---|
| Brand | OMRON |
| Model | K2CU-F10A-E |
| Category | Pressure, Flow & Temperature |
| Type | Large-capacity, built-in current transformer |
| Operate time | 0.5 s max. |
| Control output | 2 A at 220 VAC, SPDT |
| Ambient temperature | -10 to 55 °C |
| Control supply voltage | 200 VAC, 50/60 Hz |
| Operating current range | 4 to 10 A |
| Voltage fluctuation compensation | Provided |
