OMRON E6B2-CWZ1X Rotary Encoder
- Brand
- OMRON
- Model
- E6B2-CWZ1X
- GEARWELL SKU
- GWP-000003563
- Category
- Industrial Automation Parts
Key specifications
- Power supply
- 5 VDC ±5%, ripple 5% max.
- Product type
- Incremental rotary encoder, 40 mm diameter
- Maximum permissible speed
- 6,000 r/min
- Output phases
- A, B, and Z
- Resolution options
- 10 to 2,000 pulses/rotation (selected values)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON E6B2-CWZ1X is an E6B2-C incremental rotary encoder with an external diameter of 40 mm and line-driver output (AM26LS31 equivalent) on phases A, A, B, B, Z and Z. It runs on 5 VDC ±5% at 160 mA max. and is ordered with a resolution from 10 to 2,000 pulses/rotation and a 0.5 m cable, for example E6B2-CWZ1X 10P/R 0.5M; the resolution is not part of this page's number, so confirm it on the encoder label. Maximum permissible speed is 6,000 r/min, protection is IP50 and it works from −10 to 70°C.
Technical reference
| Product name | OMRON E6B2-CWZ1X Rotary Encoder |
|---|---|
| Brand | OMRON |
| Model | E6B2-CWZ1X |
| Category | Industrial Automation Parts |
| Power supply | 5 VDC ±5%, ripple 5% max. |
| Product type | Incremental rotary encoder, 40 mm diameter |
| Maximum permissible speed | 6,000 r/min |
| Output phases | A, B, and Z |
| Resolution options | 10 to 2,000 pulses/rotation (selected values) |
| Current consumption | 160 mA maximum |
| Output configuration | Line driver output |
| Maximum response frequency | 100 kHz |
