OMRON E5AC-CX3ASM-800 Temperature Controllers
- Brand
- OMRON
- Model
- E5AC-CX3ASM-800
- GEARWELL SKU
- GWP-000000027
- Category
- Industrial Automation Parts
Key specifications
- Panel size
- 96 × 96 mm
- Power supply
- 100 to 240 VAC
- Product type
- Digital temperature controller, simple type
- Control output 1
- Linear current output
- Auxiliary outputs
- 3
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON E5AC-CX3ASM-800 is a 96 × 96 mm digital temperature controller of the simple-type E5AC-800 series, with screw terminal blocks. Control output 1 is a linear current output (4 to 20 mA DC/0 to 20 mA DC, load 500 Ω max.), it has no control output 2, no communications and no event inputs, and the model code gives it three auxiliary outputs, which are SPST-NO relays rated 250 VAC, 3 A (resistive load). It takes a universal input (thermocouple, Pt100/JPt100, or analog current/voltage), samples every 50 ms and runs ON/OFF or 2-PID control with auto-tuning. It is powered from 100 to 240 VAC, 50/60 Hz (7.0 VA max. for the 800 option models), shows the PV in 25.0 mm characters and works from -10 to 55°C.
Technical reference
| Product name | OMRON E5AC-CX3ASM-800 Temperature Controllers |
|---|---|
| Brand | OMRON |
| Model | E5AC-CX3ASM-800 |
| Category | Industrial Automation Parts |
| Panel size | 96 × 96 mm |
| Power supply | 100 to 240 VAC |
| Product type | Digital temperature controller, simple type |
| Control output 1 | Linear current output |
| Auxiliary outputs | 3 |
