OMRON E3Z-T61 2M E3Z Through-beam photoelectric sensor
- Brand
- OMRON
- Model
- E3Z-T61 2M
- GEARWELL SKU
- GWP-000031347
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Output
- NPN, light-ON/dark-ON selectable
- Connection
- 2 m pre-wired cable
- Light source
- Infrared LED (870 nm)
- Response time
- 1 ms max.
- Control output
- Open collector, load current 100 mA max. at 26.4 VDC max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON E3Z-T61 2M E3Z Through-beam photoelectric sensor |
|---|---|
| Brand | OMRON |
| Model | E3Z-T61 2M |
| Category | Proximity & Photoelectric Sensors |
| Output | NPN, light-ON/dark-ON selectable |
| Connection | 2 m pre-wired cable |
| Light source | Infrared LED (870 nm) |
| Response time | 1 ms max. |
| Control output | Open collector, load current 100 mA max. at 26.4 VDC max. |
| Sensing method | Through-beam (emitter + receiver) |
| Sensing distance | 15 m |
| Degree of protection | IP67 |
| Power supply voltage | 12 to 24 VDC ±10%, ripple (p-p) 10% max. |
