OMRON E3Z-R81 2M E3Z Retro-reflective photoelectric sensor (with MSR function)
- Brand
- OMRON
- Model
- E3Z-R81 2M
- GEARWELL SKU
- GWP-000031346
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Output
- PNP, light-ON/dark-ON selectable
- Light source
- Red LED (660 nm)
- Response time
- 1 ms max.
- Control output
- Open collector, load current 100 mA max. at 26.4 VDC max.
- Sensing method
- Retro-reflective with MSR function
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON E3Z-R81 2M E3Z Retro-reflective photoelectric sensor (with MSR function) |
|---|---|
| Brand | OMRON |
| Model | E3Z-R81 2M |
| Category | Proximity & Photoelectric Sensors |
| Output | PNP, light-ON/dark-ON selectable |
| Light source | Red LED (660 nm) |
| Response time | 1 ms max. |
| Control output | Open collector, load current 100 mA max. at 26.4 VDC max. |
| Sensing method | Retro-reflective with MSR function |
| Sensing distance | 4 m (100 mm) with E39-R1S; 3 m with E39-R1 |
| Degree of protection | IP67 |
| Power supply voltage | 12 to 24 VDC ±10%, ripple (p-p) 10% max. |
