OMRON D4NL-2ADA-B 24 V DC Guard Lock Safety-Door Switch
- Brand
- OMRON
- Model
- D4NL-2ADA-B
- GEARWELL SKU
- GWP-000004514
- Category
- Machine Safety & Vision
Key specifications
- Model references
- D4NL-2ADA-B
- Condition
- Condition and availability confirmed with quotation
- Quotation
- Contact Gearwell for quotation. Confirm the exact model, condition, configuration and availability; no fixed price or stock quantity is published.
- Product type
- Guard Lock Safety-door Switch
- Conduit entry
- G1/2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON D4NL-2ADA-B is a guard lock safety-door switch from the D4NL series; this code is not in the model list, so its features were decoded from the model number legend on page 1 of the datasheet. Decoded that way, it has a G1/2 conduit outlet, a built-in switch with 1NC/1NO + 1NC/1NO slow-action contacts, a metal head with four mounting directions, mechanical lock with 24 VDC solenoid release, and an orange LED indicator for 10 to 115 VAC/VDC. The series is rated IP67, with a key holding force of 1,300 N min., 3 A at 240 V (AC-15) and an ambient operating temperature of −10 to 55°C, and the 24 VDC solenoid draws approx. 200 mA. Operation keys are sold separately.
Technical reference
| Product name | OMRON D4NL-2ADA-B 24 V DC Guard Lock Safety-Door Switch |
|---|---|
| Brand | OMRON |
| Model | D4NL-2ADA-B |
| Category | Machine Safety & Vision |
| Model references | D4NL-2ADA-B |
| Condition | Condition and availability confirmed with quotation |
| Quotation | Contact Gearwell for quotation. Confirm the exact model, condition, configuration and availability; no fixed price or stock quantity is published. |
| Product type | Guard Lock Safety-door Switch |
| Conduit entry | G1/2 |
| Locking method | Mechanical lock; solenoid release |
| Release solenoid voltage | 24 V DC |
| Head construction | Metal; four mounting directions |
| Contact arrangement | 1NC/1NO + 1NC/1NO |
