OMRON C200H-TC002 SYSMAC C200H 2-Loop Temperature Control Unit
- Brand
- OMRON
- Model
- C200H-TC002
- GEARWELL SKU
- GWP-000022038
- Category
- PLCs & I/O
Key specifications
- Weight
- 360 g
- Evidence
- OMRON operation manual Cat. No. W225-E1-05, SYSMAC C200H-TC Temperature Control Units (hosted at rgbautomatyka.pl)
- Unit type
- C200H Special I/O Unit, Temperature Control Unit
- No. of loops
- 2 (each loop: temperature sensor + CT)
- Control mode
- PID with feed-forward and auto-tuning, or ON/OFF
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON C200H-TC002 SYSMAC C200H 2-Loop Temperature Control Unit |
|---|---|
| Brand | OMRON |
| Model | C200H-TC002 |
| Category | PLCs & I/O |
| Weight | 360 g |
| Evidence | OMRON operation manual Cat. No. W225-E1-05, SYSMAC C200H-TC Temperature Control Units (hosted at rgbautomatyka.pl) |
| Unit type | C200H Special I/O Unit, Temperature Control Unit |
| No. of loops | 2 (each loop: temperature sensor + CT) |
| Control mode | PID with feed-forward and auto-tuning, or ON/OFF |
| Sensor input | Thermocouple (R, S, K, J, T, E, B, N, L, U) |
| Control output | Voltage output (pulse), 12 VDC, max. load current 40 mA (short-circuit protected) |
| Sampling period | 500 ms |
| External supply voltage | 24 VDC +10%/-15% |
| Internal current consumption | 5 VDC, 0.33 A max. |
