NORGREN F18-C00-A3DG F18 General Purpose Air Filter G2 Auto Drain
- Brand
- NORGREN
- Model
- F18-C00-A3DG
- GEARWELL SKU
- GWP-000034739
- Category
- Air Preparation
Key specifications
- Bowl
- Metal
- Drain
- Automatic (float operated)
- Weight
- 6.6 kg
- Evidence
- IMI Norgren data sheet 8.350.100.01 (cdn.norgren.com) + norgren.com product page
- Materials
- Aluminium body, intermediate body and bowl; transparent PA level indicator; NBR elastomers
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | NORGREN F18-C00-A3DG F18 General Purpose Air Filter G2 Auto Drain |
|---|---|
| Brand | NORGREN |
| Model | F18-C00-A3DG |
| Category | Air Preparation |
| Bowl | Metal |
| Drain | Automatic (float operated) |
| Weight | 6.6 kg |
| Evidence | IMI Norgren data sheet 8.350.100.01 (cdn.norgren.com) + norgren.com product page |
| Materials | Aluminium body, intermediate body and bowl; transparent PA level indicator; NBR elastomers |
| Port size | G 2 |
| Service kit | F18-100A (automatic drain, 40 µm element) |
| Filter element | 40 (sintered bronze) µm |
| Model description | General purpose filter, 2" ISO G, 40 µm, automatic drain |
| Ambient / media temperature | -34 ... 80 °C |
| Maximum operating pressure | 17 bar |
| Flow (40 µm element, 6.3 bar inlet, 0.5 bar pressure drop) | 765 dm3/s |
