National Instruments SCXI-1303 32-Channel Isothermal Terminal Block
- Brand
- National Instruments
- Model
- SCXI-1303
- GEARWELL SKU
- GWP-000026420
- Category
- Terminals, Cables & Connectors
Key specifications
- Evidence
- National Instruments installation guide 321923B-01
- CJC accuracy
- 0.5 °C (15 to 35 °C); 0.9 °C (0 to 15 °C and 35 to 55 °C)
- Type designation
- SCXI-1303
- CJC repeatability
- 0.2 °C (15 to 35 °C)
- CJC sensor output
- 1.91 to 0.58 V from 0 to 55 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | National Instruments SCXI-1303 32-Channel Isothermal Terminal Block |
|---|---|
| Brand | National Instruments |
| Model | SCXI-1303 |
| Category | Terminals, Cables & Connectors |
| Evidence | National Instruments installation guide 321923B-01 |
| CJC accuracy | 0.5 °C (15 to 35 °C); 0.9 °C (0 to 15 °C and 35 to 55 °C) |
| Type designation | SCXI-1303 |
| CJC repeatability | 0.2 °C (15 to 35 °C) |
| CJC sensor output | 1.91 to 0.58 V from 0 to 55 °C |
| Used with modules | SCXI-1102, SCXI-1102B, SCXI-1102C, SCXI-1100 |
| Number of channels | 32 differential |
| Cold-junction sensor | Thermistor |
| Number of screw terminals | 78 |
