Murrelektronik 56469 MASI AS-i Gateway AS-i gateway, 1 master
- Brand
- Murrelektronik
- Model
- 56469
- GEARWELL SKU
- GWP-000030939
- Category
- Industrial Communication
Key specifications
- Cycle time AS-i
- 150 µs × (number of slaves + 2)
- AS-i specification
- V3.0
- Supported protocol
- Ethernet/IP
- Number of slaves max.
- 62
- Operating voltage DC
- 24 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Murrelektronik 56469 MASI AS-i Gateway AS-i gateway, 1 master |
|---|---|
| Brand | Murrelektronik |
| Model | 56469 |
| Category | Industrial Communication |
| Cycle time AS-i | 150 µs × (number of slaves + 2) |
| AS-i specification | V3.0 |
| Supported protocol | Ethernet/IP |
| Number of slaves max. | 62 |
| Operating voltage DC | 24 V |
| Operating voltage DC max. | 30.6 V |
| Operating voltage DC min. | 20 V |
| Rated operating current AS-Interface max. | 250 mA |
