Moog D664-4758 D660 Servo Proportional Valve
- Brand
- Moog
- Model
- D664-4758
- GEARWELL SKU
- GWP-000019277
- Category
- Hydraulic Valves
Key specifications
- Spool
- 4-way, zero lap, linear
- Pilot stage
- ServoJet
- Seal material
- NBR
- Step response
- 18 ms @ 210 bar
- Supply voltage
- 24 (18-32) V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Moog D664-4758 D660 Servo Proportional Valve |
|---|---|
| Brand | Moog |
| Model | D664-4758 |
| Category | Hydraulic Valves |
| Spool | 4-way, zero lap, linear |
| Pilot stage | ServoJet |
| Seal material | NBR |
| Step response | 18 ms @ 210 bar |
| Supply voltage | 24 (18-32) V DC |
| Mounting pattern | ISO 4401-07-06-0-94 |
| Code as collected | MOOG D664-4758 |
| Specification note | Specifications from supplier data; please verify against the nameplate before ordering. |
| Max. operating pressure | 350 bar |
| Rated flow range (series) | 60-400 L/min |
