Mitsubishi Electric FR-A840M-03630-2-06B FR-A800 series slim model (FR-A840M) Inverter (AC variable-frequency drive, slim model)
- Brand
- Mitsubishi Electric
- Model
- FR-A840M-03630-2-06B
- GEARWELL SKU
- GWP-000030109
- Category
- Variable Frequency Drives
Key specifications
- Approx. mass
- 148 kg
- Rated voltage
- Three-phase 380 to 500 V
- Brake transistor
- Built-in (built-in brake transistor model)
- Rated current ND
- 293 A
- Rated current SLD
- 363 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric FR-A840M-03630-2-06B FR-A800 series slim model (FR-A840M) Inverter (AC variable-frequency drive, slim model) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FR-A840M-03630-2-06B |
| Category | Variable Frequency Drives |
| Approx. mass | 148 kg |
| Rated voltage | Three-phase 380 to 500 V |
| Brake transistor | Built-in (built-in brake transistor model) |
| Rated current ND | 293 A |
| Rated current SLD | 363 A |
| Protection rating (IEC 60529) | IP20 (IP55 between internal and external air regions) |
| Applicable motor capacity ND | 160 kW |
| Applicable motor capacity SLD | 200 kW |
