Mitsubishi Electric AJ65SBTB1-16T CC-Link remote transistor output module, 16 points, sink
- Brand
- Mitsubishi Electric
- Model
- AJ65SBTB1-16T
- GEARWELL SKU
- GWP-000013512
- Category
- PLCs & I/O
Key specifications
- Weight
- 0.18 kg
- Output type
- Transistor, sink
- Power supply
- 24 V DC
- Output current
- 0.5 A
- Occupied stations
- 1
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Mitsubishi Electric AJ65SBTB1-16T is a CC-Link compact type remote I/O module with 16 sink-type transistor outputs. Outputs are rated 12/24VDC at 0.5A per point and 3.6A per common, with overload, overvoltage and overheat protection. The module occupies one station with a 32-point assignment, of which 16 points are used. It runs on a 24VDC module supply at 50mA or lower, wires to an 18-point terminal block for I/O, mounts on a DIN rail and weighs 0.18kg.
Technical reference
| Product name | Mitsubishi Electric AJ65SBTB1-16T CC-Link remote transistor output module, 16 points, sink |
|---|---|
| Brand | Mitsubishi Electric |
| Model | AJ65SBTB1-16T |
| Category | PLCs & I/O |
| Weight | 0.18 kg |
| Output type | Transistor, sink |
| Power supply | 24 V DC |
| Output current | 0.5 A |
| Occupied stations | 1 |
| Rated load voltage | 12/24 V DC |
| Dimensions (W x H x D) | 118 x 50 x 40 mm |
| Integrated digital outputs | 16 |
