MEANWELL DR-4524 DR-45 Series 24 V 2 A DIN Rail Power Supply
- Brand
- MEANWELL
- Model
- DR-4524
- GEARWELL SKU
- GWP-000026471
- Category
- Power Supplies
Key specifications
- Weight
- 0.31 kg
- Rated power
- 48 W
- Rated current
- 2 A
- Efficiency (typ.)
- 80 %
- Output voltage
- 24 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL DR-4524 DR-45 Series 24 V 2 A DIN Rail Power Supply |
|---|---|
| Brand | MEANWELL |
| Model | DR-4524 |
| Category | Power Supplies |
| Weight | 0.31 kg |
| Rated power | 48 W |
| Rated current | 2 A |
| Efficiency (typ.) | 80 % |
| Output voltage | 24 VDC |
| Input voltage range | 85 ~ 264 VAC / 120 ~ 370 VDC, 47 ~ 63 Hz |
| Working temperature | -10 ~ +50 (refer to derating curve) °C |
| Dimensions (L x W x H) | 93 x 78 x 67 mm |
| Voltage adjustment range | 21.6 ~ 26.4 V |
