LS Electric MMS-32S 0.16A Metasol Manual Motor Starter
- Brand
- LS Electric
- Model
- MMS-32S 0.16A
- GEARWELL SKU
- GWP-000021671
- Category
- Contactors & Starters
Key specifications
- Weight
- 320 g
- Number of poles
- 3
- Rated operational current (Ie)
- 0.16 A
- Rated operational voltage (Ue)
- up to 690 V AC
- Motor power AC-3 at 230 V / 400 V
- - / 0.02 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | LS Electric MMS-32S 0.16A Metasol Manual Motor Starter |
|---|---|
| Brand | LS Electric |
| Model | MMS-32S 0.16A |
| Category | Contactors & Starters |
| Weight | 320 g |
| Number of poles | 3 |
| Rated operational current (Ie) | 0.16 A |
| Rated operational voltage (Ue) | up to 690 V AC |
| Motor power AC-3 at 230 V / 400 V | - / 0.02 kW |
| Thermal release adjustment range | 0.1 ... 0.16 A |
| Magnetic release operating current | 2.1 A |
| Breaking capacity Icu / Ics at 400/415 V | 100 / 100 kA |
