LS Electric iXP2-1000A iXP2 Series 10.4-inch HMI Touch Panel
- Brand
- LS Electric
- Model
- iXP2-1000A
- GEARWELL SKU
- GWP-000024433
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- 1 GHz dual-core
- Memory
- 1 GB flash / 1 GB RAM / 1 MB backup RAM
- Display
- 10.4" TFT colour LCD, 16.7M colours, LED backlight
- Ethernet
- 1 x 10/100Base-TX, 1 x 10/100/1000Base-TX
- Protection
- IP66, UL type 4X / NEMA 4X
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | LS Electric iXP2-1000A iXP2 Series 10.4-inch HMI Touch Panel |
|---|---|
| Brand | LS Electric |
| Model | iXP2-1000A |
| Category | HMIs & Industrial PCs |
| CPU | 1 GHz dual-core |
| Memory | 1 GB flash / 1 GB RAM / 1 MB backup RAM |
| Display | 10.4" TFT colour LCD, 16.7M colours, LED backlight |
| Ethernet | 1 x 10/100Base-TX, 1 x 10/100/1000Base-TX |
| Protection | IP66, UL type 4X / NEMA 4X |
| Touch panel | Capacitive (multi-touch) |
| Power supply | 100-240 V AC (A version) |
| Serial ports | 1 x RS-232C (D-SUB 9), 1 x RS-422/485 (isolated) |
| Panel cut-out | 259.0 x 201.0 mm |
