KYORITSU 5720 KEW 5720 High/Low Voltage Detector
- Brand
- KYORITSU
- Model
- 5720
- GEARWELL SKU
- GWP-000022713
- Category
- Test & Measurement
Key specifications
- Weight
- approx. 230 g
- Battery
- R03 (AAA) x 2
- Frequency
- 50/60 Hz
- Withstand voltage
- AC 20 kV for 1 min (extended)
- Detection voltage range
- AC 80-7000 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KYORITSU 5720 KEW 5720 High/Low Voltage Detector |
|---|---|
| Brand | KYORITSU |
| Model | 5720 |
| Category | Test & Measurement |
| Weight | approx. 230 g |
| Battery | R03 (AAA) x 2 |
| Frequency | 50/60 Hz |
| Withstand voltage | AC 20 kV for 1 min (extended) |
| Detection voltage range | AC 80-7000 V |
| Length (retracted / extended) | 256 / 717 mm |
| Operating start voltage (low / high) | bare wire 80 V / 400 V |
