Kongsberg MRU H Motion Reference Unit Heave Compensator
- Brand
- Kongsberg
- Model
- MRU H
- GEARWELL SKU
- GWP-000026480
- Category
- Encoders & Position
Key specifications
- Interfaces
- RS-422/RS-232 serial ports, 5 Ethernet UDP/IP output ports 10/100 Mbps
- Seller code
- MRU-H
- Voltage input
- 10 - 36 VDC
- Power consumption
- Max 8 W (typical 7.2 W)
- Weight / dimensions
- 2.2 kg, Ø 105 x 140 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Kongsberg MRU H Motion Reference Unit Heave Compensator |
|---|---|
| Brand | Kongsberg |
| Model | MRU H |
| Category | Encoders & Position |
| Interfaces | RS-422/RS-232 serial ports, 5 Ethernet UDP/IP output ports 10/100 Mbps |
| Seller code | MRU-H |
| Voltage input | 10 - 36 VDC |
| Power consumption | Max 8 W (typical 7.2 W) |
| Weight / dimensions | 2.2 kg, Ø 105 x 140 mm |
| Data output rate (max) | 200 Hz |
| Static accuracy roll & pitch | 0.03° RMS |
| Operating temperature / enclosure | -5 to +55 °C, IP66 |
| Heave accuracy (delayed, 0-50 s periods) | 1 cm or 1 % (RMS), whichever is highest |
| Dynamic accuracy roll & pitch (±5° amplitude) | 0.010° 1-sigma |
| Heave accuracy (real-time, 0-25 s periods) | 5 cm or 5 % (RMS), whichever is highest |
