Kollmorgen S62000 SERVOSTAR 620 Digital Servo Amplifier
- Brand
- Kollmorgen
- Model
- S62000
- GEARWELL SKU
- GWP-000026481
- Category
- Servo Systems
Key specifications
- Evidence
- Kollmorgen SERVOSTAR 601...620 Instructions Manual, edition 07/2016 (kollmorgen.com)
- Device name
- SERVOSTAR 620
- Seller code
- SERVOSTAR TM620 S62000
- Rated supply voltage
- 3 x 230 V -10% ... 480 V +10%, 50 Hz (3 x 208-480 V, 60 Hz)
- Rated installed load (S1)
- 14 kVA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Kollmorgen S62000 SERVOSTAR 620 Digital Servo Amplifier |
|---|---|
| Brand | Kollmorgen |
| Model | S62000 |
| Category | Servo Systems |
| Evidence | Kollmorgen SERVOSTAR 601...620 Instructions Manual, edition 07/2016 (kollmorgen.com) |
| Device name | SERVOSTAR 620 |
| Seller code | SERVOSTAR TM620 S62000 |
| Rated supply voltage | 3 x 230 V -10% ... 480 V +10%, 50 Hz (3 x 208-480 V, 60 Hz) |
| Rated installed load (S1) | 14 kVA |
| Expansion suffix options | NA (none) / DN (DeviceNet) / PB (PROFIBUS) / SE (SERCOS) / SN (SynqNet) (specify on order) |
| Rated output current (rms) | 20 A |
| Rated DC bus link voltage | 290 - 675 V DC |
| Electrical option position | 0 = no option |
| Peak output current (approx. 5 s) | 40 A |
