Kistler 9327C 93x7C 3-Component Piezoelectric Force Link
- Brand
- Kistler
- Model
- 9327C
- GEARWELL SKU
- GWP-000021662
- Category
- Test & Measurement
Key specifications
- Weight
- 0.380 kg
- Sensitivity Fz
- ≈ -3.8 pC/N
- Connecting plug
- V3 neg.
- Overload Fx, Fy, Fz
- ≤ 20 %
- Sensitivity Fx, Fy
- ≈ -7.8 pC/N
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Kistler 9327C 93x7C 3-Component Piezoelectric Force Link |
|---|---|
| Brand | Kistler |
| Model | 9327C |
| Category | Test & Measurement |
| Weight | 0.380 kg |
| Sensitivity Fz | ≈ -3.8 pC/N |
| Connecting plug | V3 neg. |
| Overload Fx, Fy, Fz | ≤ 20 % |
| Sensitivity Fx, Fy | ≈ -7.8 pC/N |
| Measuring range Fz (centric) | -8 ... 8 kN |
| Operating temperature range | -40 ... 120 °C |
| Measuring range Fx, Fy (without moment load) | -4 ... 4 kN |
