KIMO TH110-ANES TH 110 Humidity and Temperature Transmitter
- Brand
- KIMO
- Model
- TH110-ANES
- GEARWELL SKU
- GWP-000022706
- Category
- Pressure, Flow & Temperature
Key specifications
- Probe (ES)
- Standard model (as named in the Quick Start Guide)
- Display (N)
- Without display
- Protection
- IP65 (duct, remote and standard models)
- Part number
- TH110-ANES (listed in the 0-10 V active model group)
- Supply / output (A)
- Active 0-10 V, 24 V AC/DC ±10 %, 3-4 wires
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KIMO TH110-ANES TH 110 Humidity and Temperature Transmitter |
|---|---|
| Brand | KIMO |
| Model | TH110-ANES |
| Category | Pressure, Flow & Temperature |
| Probe (ES) | Standard model (as named in the Quick Start Guide) |
| Display (N) | Without display |
| Protection | IP65 (duct, remote and standard models) |
| Part number | TH110-ANES (listed in the 0-10 V active model group) |
| Supply / output (A) | Active 0-10 V, 24 V AC/DC ±10 %, 3-4 wires |
| Humidity resolution | 0.1 %RH |
| Operating conditions | -10...+50 °C, non-condensing, 0...2000 m |
| Temperature resolution | 0.1 °C |
| Humidity measuring range | 5...95 %RH |
